2006 Suzuki QuadRacer® R450™ for Sale

New Chassis

• All new high-tensile steel frame designed for optimum rigidity, maximum durability and features a compact and lower profile for a lower center of gravity and unmatched cornering performance
• New race-ready steel rear swingarm providing 3 times more flexibility and a smoother arc of movement for optimum handling performance in any environment
• All new wider independent double wishbone front suspension with fully adjustable Kayaba piggyback reservoir style front shocks featuring 40 mm pistons and a sturdy 14 mm shock rod for superb damping and incredible performance
• Kayaba rear shock features adjustable high and low speed compression, rebound and preload with a 50 mm piston, 18 mm rod and piggyback reservoir design providing 290 mm of rear wheel travel
• Special Dunlop radial tires designed specifically for the LT-R450 combined with smaller 10 x 5.5 inch aluminum rear wheels and 18 x 10 inch aluminum front wheels for a lower center of gravity and superb cornering stability
• High performance dual hydraulic front disc brakes with 160 mm front rotors and a single hydraulic rear brake caliper mounted on a forged aluminum mounting bracket and a 190 mm rear disc
• Rugged Serrated large footpegs provide excellent grip and control
• Aggressive new styling highlights the high performance nature of the QuadRacer R450 The LT-R450 is styled with a low and wide profile to further emphasize the lightweight performance intent of the machine
• The LT-R450 has a GSX-R and Hayabusa inspired multi-reflector headlight that is easily removable with a single bolt and an ultra compact LED tailight at the rear
• Aggressively styled radiator shrouds, front and rear fenders, and T-shaped seat provide a sharp new look and maximum rider mobility for the control

New Engine

• All new 4-stroke, 1-cylinder, fuel injected, liquid-cooled, DOHC. Four valve engine designed to be compact, lightweight and provide incredible performance
• Innovative Suzuki Advanced Sump System allows the engine mass and crankshaft to be positioned close to the ground for a low center of gravity and also keeping the engine as short as possible
• Aluminum cylinder bore is electro-plated with Suzuki's own race proven SCEM (Suzuki Composite Electrochemical Material for improved heat transfer, lightweight and tighter piston clearance
• Lightweight magnesium clutch cover, magneto cover, and cylinder head cover for minimal weight and maximum durability
• Lightweight and durable titanium valves are used for precise valve control at high rpm and reduced reciprocating mass. Titanium intake valves measure 36 mm and 29 mm on the exhaust
• Lightweight forged aluminum pistons use a new 3-ring design with cutaway sides, oil retaining grooves for reduced friction and the oil control ring features a high performance chrome nitride plating for less friction and improved strength
• New five speed transmission is exceptionally compact with larger 1st and 2nd gears mounted outboard while the 3rd, 4th and 5th gears are mounted inside for a compact engine layout and superb handling
• The LT-R450 utilizes a convenient electric starter for easier starts with a kick starter available as an optional kit
• A new high capacity radiator is used to handle the high performance engine output combined with a compact and lightweight, ring type cooling fan for maximum efficiency
• Advanced and lightweight electronic fuel injection system with a 42 mm bore and multi hole type injector for optimum atomization, smooth throttle response and maximum performance
• New cylinder head features a narrow included valve angle creating a compact cylinder head design, compact combustion chamber and featuring 12.0:1 compression ratio for maximum performance
• High performance ECM utilizes a high spec 16 bit CPU for quick fuel injection calculations and is designed to compact and lightweight
• All new stainless steel center exhaust system utilizes a compact centrally located muffler layout for improved mass centralization, improved stability, and higher cornering performance
